DIAL INDICATOR 30/0.01MM 2052S MITUTOYO MT0000388

DIAL INDICATOR 30/0.01MM 2052S adalah satu alat ukur yang dapat mengukur kerataan benda kerja. Dial indicator Mitutoy omemungkinkan kita untuk memeriksa kerataan dari permukaan benda, me meriksa penyimpangan yang kecil pada bidang , memeriksa penyimpangan e ksentris, memeriksa kesejajaran permukaan benda, menyetel kesentrisan be nda pada pencekam mesin bubut, dan memeriksa penyimpangan bantalan pada poros engkol . Dial indicator Mitutoyo tipe Long Stroke dengan pe mbacaan 0-100 dan range pengukuran 0-30 MM sering digunakan di industr i, bengkel, laboratorium, atau konstruksi.

• The stem spindle is made of high strength quench hardened stainless steel which resists strenuous use also carbide contact point is used
• The grand gear uses stainless steel that is resistant to wear and deformation, application of a hard coating on the surface of the crystal makes the gauge highly scratch and chemical resistant
• Ste m diameter 8MM, M2.5-0.45 thread size and measuring force is 2.5N or less
• With damper at lowest rest point
• Provided with inspec tion certificate

• Additional Features : –
• Color : White
• Display : 0-100
• EAN : 4946368428918
• Maximum Measurement : 0-30MM
• Measurement Accuracy : +/-0.025MM
• Number of Items : 1
• Outside Diameter : 57 MM
• Part Number : 2052S
• Range : 0-30MM
• Resolution : 0.01MM
• Shape : Lug Back
• Size : 0-30MM Range
• Style Name : 0-100
