Power Quality Analyzer 500A Kyoritsu KEW 6315-01

Ada Stock

Spesifikasi Produk Power Quality Analyzer 500A Kyoritsu KEW 6315-01 :

SKU : 6315-01

Size : 175 x 120 x 65 mm

Power Quality Analyzer 500A Kyoritsu KEW 6315-01

Dapatkan Produk Kyoritsu dengan harga terbaik hanya di alatproyek.com / hubungi 021-29986622 s/d 24, 081808090252

Rp 55.320.000,00

Deskripsi Produk Power Quality Analyzer 500A Kyoritsu KEW 6315-01 :

Power Quality Analyzer 500A Kyoritsu KEW 6315-01

The power analyser Kyoritsu 6315 is used for the analysis of performance and harmonics. The power analyser can safely measure currents of up to 3000 A. Besides the performance analysis, the power analyser can execute a complete network analysis. The power analyser also measures the phase angle, harmonics, apparent power, active power and work. All measurable variables are shown on the colour display of the power analyser 6315. The power analyser’s built-in memory has a size of 3 MB therefore is sufficient for a data record of about 2 days. The memory of the power analyser can be extended by an additional CF card. The Maximum memory capacity is 2 GB. The power analyser is the large version of harmonics-analyser Kyoritsu 6300. If you have any questions concerning the power analyser, please take a look at the following technical data. Our technicians and engineers will gladly advise you on the power analyser or any other of PCE  products in the fields of regulation and control, or scales and balances of PCE Instruments.

Fitur :

  • Simultaneous Power & Power quality measurements
  • Helpful support functions
  • Measurement with high accuracy
  • Remote monitoring on PC and Android device
  • Various Clamp Current Sensors
  • Energy consumption check on site
  • IEC 61010-1 CAT IV 300V, CAT III 600V, CAT II 1000V
Spesifikasi :
  • Technical Specification  Power Analyser Kyoritsu 6315
  • Voltage measurement
  • Range    150 V / 300 V / 600 V / 1000 V
  • Display    4 digits
  • Accuracy (45 ... 65 Hz)    ± 0.3 % rdg ± 0.2 % f.s.
  • Overload protection    1200 V
  • Current measurement
  • Range converter Flex 3000A    300 A / 1000 A / 3000 A
  • Display    4 digits
  • Accuracy (45 ... 65 Hz)    ± 0.3% rdg ± 0.2% f.s.
  • plus measurement uncertainty of the current transformer
  • Active Power
  • Range    Range voltage x current range
  • Display    4 digits
  • Accuracy (45 ... 65 Hz sine wave)    ± 0.5% rdg ± 0.2% f.s.
  • plus measurement uncertainty of the current transformer
  • Frequency
  • Range    40 ... 70 Hz
  • Display    4 digits
  • Accuracy    ± 0.5% f.s.
  • General technical specification for Power Analyser
  • Display    320 x 240 (RGB) pixels, 3.5-inch colour display
  • Memory interval (adjustable)    1/2/5/10/15/20/30 seconds
  • 1/2/5/10/15/20/30/60 minutes
  • Viewing Time    1 second
  • Interface    USB and Bluetooth
  • Memory    3 MB (internal, enough for about 2 days at 30 min)
  • up to 2 GB (expandable via CF card)
  • Security    CAT III / 600 V
  • Standardization    IEC / EN 61010-1
  • IEC / EN 61010-031
  • Power supply    100 ... 240 V AC 50/60 Hz
  • 6 x 1.5V AA battery
  • Standby battery operation    about 7 hours
  • Operating conditions    0 ... 50 ° C / 85% RH non-condensing
  • Storage Conditions    -20 ... +60 ° C / 85% RH non-condensing
  • Dimensions    175 x 120 x 65 mm
  • Weight    about 800 g with battery
