Insulation Tester Hioki IR4058-20

Fitur Insulation Tester Hioki IR4058-20:

• Measured values held on the display are sent immediately to a smartphone or tablet via Bluetooth wireless technology.
• Easily manage measured data and create simple PDF reports in the field.
• High-speed model, built in Bluetooth Smart
• Measured values held on the display are sent immediately to a smartphone or tablet via Bluetooth Smart technology (IR4058)
• 5-range testing voltage of 50 V/100 M to 1000 V/4000 M
• Digital bar graph
• Stable & high-speed digital readings, 0.3 second response time for PASS/ FAIL decisions
• Drop proof onto concrete from 1m (3.28 feet)
• Bright LED, luminous LCD, test lead with bright LED lamp to illuminate near hand (Option L9788-11 or L9788-10)
• Continuity check via 200 mA testing
• Built in AC/DC voltage meter, useful for testing solar power generation systems and electric vehicles

Spesifikasi Detail Insulation Tester Hioki IR4058-20:

General Specifications
Rated output voltage 50 V DC 125 V DC 250 V DC 500 V DCC 1000 V DC
Effective maximum indicated value 100 M 1250 M 500 M 2000 M 4000 M
Accuracy 1st effective measuring range M 2 % rdg. 2 dgt.
0.200 - 10.00 2 % rdg. 2 dgt.
0.200 - 25.0 2 % rdg. 2 dgt.
0.200 - 50.0 2 % rdg. 2 dgt.
0.200 - 500 2 % rdg. 2 dgt.
0.200 - 1000
Lower limit resistance 0.05 M 0.125 M; 0.25 M 0.5 M 1 M
Overload protection 600 V AC (10s) 660 V AC (10s)
DC voltage measurement 4.2 V (0.001 V resolution) to 600 V (1 V resolution), 4 ranges,
Accuracy: 1.3% rdg. 4 dgt., Input resistance: 100 k or higher
AC voltage measurement 420 V (0.1 V resolution) / 600 V (1 V resolution), 2 ranges, 50/60 Hz,
Accuracy: 2.3% rdg. 8 dgt., Input resistance: 100 k or higher, Average rectifier
Low resistance measurement For checking the continuity of ground wiring, 10 (0.01 resolution) to 1000 (1 resolution), 3 ranges, Basic accuracy: 3 %
rdg. 2 dgt., testing current 200 mA or more (at 6 or less)
Display Semi-transmissive FSTN LCD with back lighting, bar-graph indicator
Response time Approx. 0.3 second for PASS/FAIL decision (based on in-house testing)
Other functions Indicate M measurement value after a lapse of one minute, Live circuit indicator, Automatic electric discharge, Automatic DC/AC
detection, Comparator, Drop proof, Auto power save
Interface (IR4058 only) Bluetooth 4.0LE (Bluetooth SMART), Supported devices: iOS 8 or later, Android 4.3 or later smartphone/tablet
GENNECT Cross (free downloadable app) : display measured values, Simple logging function, Hold save function
Power supply LR6 (AA) alkaline batteries 4, Continuous use: 20 hours (based on in-house testing), 10 hours (Bluetooth ON)
Dimensions and mass 159 mm (6.26 in)W 177 mm (6.97 in)H 53 mm (2.09 in)D, 640 g (22.6 oz) (including batteries, excluding test leads)
Accessories Test lead L9787 1, Neck strap 1, Instruction manual 1, LR6 (AA) alkaline batteries 4
