INSULATION TESTER HIOKI IR4053-10

Ada Stock

SPESIFIKASI PRODUK INSULATION TESTER HIOKI IR4053-10 :

SKU : IR4053-10

Size : 159 mm (6.26 in) W × 177 mm H (6.97 in) H × 53 mm (2.09 in) D

INSULATION TESTER HIOKI IR4053-10

Dapatkan produk Hioki dengan harga terbaik hanya di alatproyek.com / hubungi 021-29986622 s/d 24, 081808090252


Rp 5.650.000,00

DESKRIPSI PRODUK INSULATION TESTER HIOKI IR4053-10 :

INSULATION TESTER HIOKI IR4053-10

Fitur :

  • Safely and accurately measure PV insulation resistance even while generating solar power
  • Built-in PV dedicated function, display measurements in 4 seconds
  • Five ranges (50/125/250/500/1000V) built in for normal insulation resistance measurement
  • Built-in 1000 VDC voltage measurement for open voltage tests of PV systems that support 1000 V
  • Built-in comparator function
  • Drop proof design withstands drop onto concrete from a height of 1 meter

Spesifikasi :

Spesifikasi
 Rated output voltage  DC 500 V  DC 1000 V
 Effective maximum indicated value  2000 MΩ  4000 MΩ
 Measuring range/ Accuracy  0.200 to 500 MΩ / ±4% rdg.
 501 to 2000 MΩ / ±8% rdg.
 0.200 to 1000 MΩ / ±4% rdg.
1010 to 4000 MΩ / ±8% rdg.
 Other measuring range / Accuracy  0 to 0.199 MΩ / ±2% rdg. ±6 dgt.
 Rated output voltage  DC 50 V  DC 125V  DC 250 V  DC 500V  DC 1000
 Effective maximum indicated value  100 MΩ  250 MΩ  500 MΩ  2000 MΩ  4000 MΩ
 Accuracy 1st effective measuring range MΩ  ±4% rdg.
0.200 to 10.00
 ±4% rdg.
0.200 to 25.0
 ±4% rdg.
0.200 to 50.0
 ±4% rdg.
0.200 to 500
 ±4% rdg.
0.200 to 1000
 Lower limit resistance  0.05 MΩ  0.125 MΩ  0.25 MΩ  0.5 MΩ  1 MΩ
 DC voltage measurement  4.2 V (0.001 V resolution) to 1000 V (1 V resolution), 4 ranges,
Accuracy: ±1.3% rdg. ±4 dgt., (Ranges in excess of 1000 V are not guaranteed for accuracy.)
 AC voltage measurement  420 V (0.1 V resolution)/600 V (1 V resolution), 2 ranges, 50/60 Hz,
Accuracy: ±2.3% rdg. ±8 dgt., (Ranges in excess of 600 V are not guaranteed for accuracy.)
 Display  Semi-transmissive FSTN LCD with back lighting, Backlight
 Response Time  Insulation resistance range: 1 second, PVΩ function: 4 seconds (based on in-house tests)
 Other Functions  Live circuit indicator, automatic electric discharge, automatic DC/AC detection, comparator, drop proof, auto power save
 Power Supply  AA alkaline batteries (LR6) ×4, Continuous operating time: Approx. 20 hours (based on in-house tests)
 Dimensi dan Berat  159 mm (6.26 in) W × 177 mm H (6.97 in) H × 53 mm (2.09 in) D, Approx. 600 g (21.2 oz) (including batteries, excluding test lead)
