DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394

Be the first to review this product

Rp 1.918.000,00

In stock

SKU

MT0000394

Spesifikasi Produk DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 -Include PPn-

SKU : MT0000394

Size : 130 x 80 x 58 mm

DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 -Include PPn-

Dapatkan Produk Mitutoyo dengan harga terbaik hanya di alatproyek.com / hubungi 021-29986622 s/d 24, 081808090252

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Details

Deskripsi Produk DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 -Include PPn-

DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 -Include PPn-

DIAL INDICATOR 2/0.001MM 2113S-10 adalah satu alat ukur yang dapat mengukur kerataan benda kerja. Dial indicator Mitutoyo memungkinkan kita untuk memeriksa kerataan dari permukaan benda, memeriksa penyimpangan yang kecil pada bidang , memeriksa penyimpanga n eksentris, memeriksa kesejajaran permukaan benda, menyetel kesentrisan benda pada pencekam mesin bubut, dan memeriksa penyimpangan bantalan pada poros engkol . Dial indicator Mitutoyo standard mempunyai range pengukuran 0-2 MM dan pembacaan 0-100-0 sering digunakan di industri , bengkel, laboratorium, atau konstruksi.

Benefit :

Standard 0.001MM and 0.005MM graduation dial indicators having a bezel with an outside diameter of Dia.57MM. All types come with limit markers and a bezel clamp.
The outer clamp and lifting lever (optional) can be attached to either the right or left side. These part s can be easily installed and removed without tools.
Secure adhesi on between the bezel and crystal as well as the use of an O-ring prevent s water or oil penetration.
The spindle is made of high-strength quenchhardened stainless steel which resists arduous use.
A car bide contact point is used.
A special alloy is used for the sector gears to provide improved wear resistance.
The indicator uses jeweled bearings, providing excellent indication sensitivity and durability.
Application of a hard coating on the surfac e of the crystal makes the gauge highly scratch- and chemical-resistant.

Fitur :

The stem spindle is made of high strength quench hardened stainless steel which resists strenuous use also carbide contact point is used
The grand gear uses stainless steel that is resistant to wear and deformation, application of a hard coating on the surface of the crystal makes the gauge highly scratch and chemical resistant
Ste m diameter 8MM, M2.5-0.45 thread size and Measuring force is 1.5N or less
Shockproof, jeweled bearing
Provided with inspection certificate

Spesifikasi :

Part Number : 2113S-10
Style Name : 0-100
Maximum Measurement : 0-2MM
Additional Features : Shockproof, Jeweled Bearing
Color : White
Display : 0-100-0
EAN : 4946368423470
Measurement Accuracy : +/-0.007MM
Numb er of Items : 1
Outside Diameter : 57 MM
Range : 0-2MM
Resolution : 0.001MM
Shape : Lug Back
Size : 0- 2MM Range

DIAL INDICATOR 2/0.001MM 2113S-10 Mitutoyo MT0000394 -Include PPn-
