Cable Reel Set Model Kyoritsu KEW 4105DL

Deskripsi Produk Cable Reel Set Model Kyoritsu KEW 4105DL

Cable Reel Set Model Kyoritsu KEW 4105DL

Fitur :

• 3pole and 2pole Earth Resistance measurement (0.01-2000)
• Waterproof design (IP67)
• Rotary Switch makes the user interface very intuitive
• Large LCD Display with Backlight
• Led to monitor correct / non correct auxiliary earth spike resistance
• Earth Voltage Measurement (AC/DC 0-300V)
• CAT 100V

Spesifikasi :

• Earth resistance
• measurement 20 200 2000
• Measuring range 0.00 - 2000
• Display range 0 - 2099
• Accuracy*1 1.5%rdg0.08 *2 1.5%rdg4dgt
• Auxiliary earth resistance*3 <10k <50k <100k
• Comparator reference value 10 100 500
• Earth voltage measurement
• Measuring range 0 - 300 V AC (45 - 65Hz) 0 - 300 V DC
• Display range 0.0 - 314.9 V 0.0 - 314.9 V
• Accuracy 1%rdg4dgt
• Overload protection Earth resistance : 360V AC (10 seconds)
• Earth voltage : 360V AC (10 seconds)
• Applicable Standards IEC 61010-1, CAT IV 100 V /CAT III 150 V /CAT II 300 V Pollution degree 3
• IEC 61010-2-030,IEC 61010-031, IEC 61557-1, -5
• IEC 60529 IP67, IEC 61326-1, -2-2, EN50581(RoHS)
• Power source LR6(AA)(1.5V) 6
• Dimensions 121(L) 188(W) 59(H) mm (including case lid)
• Accessories
• for 4105DL 7127B(Simplified measurement probe)
• 8041(Auxiliary earth spikes[2 spikes/1set])
• 9121(Shoulder strap)
• 7267(Cable reel for Earth resistance tester (red))
• 7268(Cable reel for Earth resistance tester (yellow))
• 7271(Earth resistance test leads)
• 9190(Carrying case)
• LR6(AA) 6, Instruction manual
